Profine® Blue Line
PROFINE® BLUE removes bad taste and odour, reduces turbidity, chlorine, dirty and particles it has a 5mc nominal filtration. It is a cartridge with an activated Profine® Carbon Block technology in compliance with the Italian Ministerial Decree DM/25/2012.
- REMOVES BAD ODOURS AND OFF-TASTES
- REDUCES CHLORINE
- REDUCES WATER TURBIDITY
Dechlorination and purification of drinking water
PROFINE® BLUE is a quick-connect disposable cartridge with Profine® Carbon Block technology filtration; filtration of 5 microns. Activated carbon filter for dechlorination and clarification of drinking water, according to EU Directive 98/83/EC. The filtration reduces chlorine content, organic compounds, odours/off-tastes from water. If used in equipment for drinking water treatment, the equipment must comply with the standards of law for this category of treatment systems. Installation: upright or horizontal, as preferred.
TECHNICAL SPECIFICATIONS
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| Flow rate | 3 l/min * | 5 l/min * | 7 l/min * |
| Capacity | 15.000 l * | 24.000 l * | 45.000 l * |
| Working pressure | Min. 2 – Max. 6 Bar | Min. 2 – Max. 6 Bar | Min. 2 – Max. 6 Bar |
| Temperature | Min. 4 Max. 30°C (40-86°F) |
Min. 4 Max. 30°C (40-86°F) |
Min. 4 Max. 30°C (40-86°F) |
* Capacities may vary based on incoming water and flow rates.
CHECK OF PARAMETER CHANGE
| PARAMETER | EU DIRECTIVE 98/83 | TESTING WATER QUALITY | TREATED WATER QUALITY |
|---|---|---|---|
| Iron | 0,20 mg/l | ≥ 0,15 / ≤ 0,17 mg/l | ≥ 0,106 / ≤ 0,166 mg/l |
| Chlorine | 0,20 mg/l | 1,00 mg/l | ≥ 0,1 mg/l / ≤ 0,2 mg/l |
| pH | ≥ 6,5 e ≤ 9,5 | average 8,22 | average 8,33 |
| Conductivity | 2500 μScm-1 a 20 °C | average 383 | average 355 |
| Manganese | ≤ 0,05 mg/l | 0.0004 mg/l | 0.0001 mg/l |
DIMENSIONS
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| Diameter | 87,4 mm | 87,4 mm | 87,4 mm |
| Heigth (without head) | 270 mm | 385 mm | 530 mm |
| Heigth (with head) | 302 mm | 417 mm | 562 mm |
We recommend replacing the cartridge at the end of its nominal range, or if the output flow ate is
too slow. It’s better that you replace the cartridge within 365 days of its installation. Before removing
the cartridge, close the upstream water inlet and eliminate the pressure in the circuit by opening the
downstream tap. To activate the cartridge correctly, open the inlet valve and supply water for at least
five minutes before drinking it.
