Pfas

Profine Cartridge

PROFINE® PFAS LINE

PROFINE® PFAS removes Perfluoroalkyls (Pfas) and bad odours and off-tastes in drinking water. Pfas selective resin, 0.5 μm final filtration stage with Profine® Carbon Block technology added with silver ions for bacteriostatic action. To be used with a Pfas concentration of less than 500 ng / l.

  • REMOVES BAD ODOURS AND OFF-TASTES AND REDUCES CHLORINE
  • BACTERIOSTATIC FEATURE
  • REDUCE PFAS CONCENTRATION


Reduction of Pfas and microfiltration

PROFINE® PFAS is a disposable filter for drinking water treatment with selective Pfas resin.The Profine® filter has a 0.5 μm final filtration step with bacteriostatic Profine® Carbon Block Silver technology.

TECHNICAL SPECIFICATIONS

MEDIUM* LARGE
Flow rate 2 l/min * 2 l/min *
Capacity 11.000 l * 11.000 l *
Working pressure Min. 2 – Max. 6 Bar Min. 2 – Max. 6 Bar
Temperature Min. 4 Max. 30°C
(40-86°F)		 Min. 4 Max. 30°C
(40-86°F)
*Flow rates can vary, even to a considerable extent, depending on the quality of the incoming water.
* Medium filter can not be used singularly.

DIMENSIONS

MEDIUM LARGE
DIAMETER 87,4 mm 87,4 mm
HEIGHT (without head) 384 mm 529 mm
HEIGHT (with head) 420 mm 560 mm


Domestic filtration kit that removes pfas

KIT PROFINE® PFAS is a disposable type cartridge for drinking water treatment with selective Pfas resin.
The Profine® filter with quick coupling features a 0.5 μm final filtration step with bacteriostatic Profine® Carbon Block Silver technology.

TECHNICAL SPECIFICATIONS

MEDIUM* LARGE
Flow rate 2 l/min* 2 l/min*
Capacity 11.000 l * 11.000 l *
Working Pressure Min. 2 – Max. 6 Bar Min. 2 – Max. 6 Bar
Temperature Min. 4 Max. 30°C
(40-86°F)		 Min. 4 Max. 30°C
(40-86°F)
*Flow rates can vary, even to a considerable extent, depending on the quality of the incoming water.
* Medium filter can not be used singularly.

KIT DIMENSIONS

KIT MEDIUM
DIAMETER 200 mm
HEIGHT (without head) 384 mm

REPLACEMENT CARTRIDGE DIMENSIONS

MEDIUM LARGE
DIAMETER 87,4 mm 87,4 mm
HEIGHT (without head) 384 mm 529 mm


Reduction of the Pfas
and microfiltration

BIG PROFINE® PFAS It is ideal for professional use where large quantities of refined water are needed. The cartridge must be powered only with cold water. Thanks to the multi-stage concept that combines the selective pfas resin and Profine® Carbon Block technology, the Profine® BIG Pfas cartridge offers the guarantee of a good and safe water by eliminating the Pfas.

TECHNICAL SPECIFICATIONS

BIG 2.0 BIG 3.0 BIG 4.5 BIG 6.0
Flow rate 2 l/min * 3 l/min * 4,5 l/min * 6 l/min *
Capacity 11.000 l * 16.500 l * 24.750 l * 33.000 l *
Working pressure Min. 2 – Max. 6 Bar Min. 2 – Max. 6 Bar Min. 2 – Max. 6 Bar Min. 2 – Max. 6 Bar
Temperature Min. 4 Max. 30°C
(40-86°F)		 Min. 4 Max. 30°C
(40-86°F)		 Min. 4 Max. 30°C
(40-86°F)		 Min. 4 Max. 30°C
(40-86°F)
Autonomy calculated on a water with a concentration of Pfas equal to 500 ng / l
* Based on internal manufacturer tests

DIMENSIONS

BIG 2.0 BIG 3.0 BIG 4.5 BIG 6.0
DIAMETER 134 mm 137 mm 167 mm 171 mm
HEIGHT 285 mm 374 mm 381 mm 451 mm
We recommend replacing the cartridge at the end of its nominal range, or if the output flow ate is
too slow. It’s better that you replace the cartridge within 365 days of its installation. Before removing
the cartridge, close the upstream water inlet and eliminate the pressure in the circuit by opening the
downstream tap. To activate the cartridge correctly, open the inlet valve and supply water for at least
five minutes before drinking it.
